Cadtoday Projects


Below is a selection of projects we have been involved with.



Snowdon Mountain Railways.(SMR)

SMR required visualisations for a External temporary workshop facility.  This was to be used to support an application to the local authority. The temporary structure would increase their capacity for maintaining the new fleet of lightweight carriages, which we had also helped design earlier in the year.  The new service is now bringing benefits to the railway as more passengers are able to experience this Iconic mountain railway.

Specialist Spring Manufacturer

Working with a Specialist Spring Manufacturer we provided a measure and draw service for an newly developed Bed Mattress assembly machine. Using solid modelling CAD software we produced full set of detailed drawings and itemised Assemblies for manufacture.  The 3D solid models were rendered to be used in advertising and maintenance and assembly manuals.

School Hall Structural Steel framework.

Working with a local Specialist steelwork fabrication company we created a 3D model for the Initial GA based on the Architects plans. The frame, foundation fixing details and basic connection details were drawn and submitted for approval. On approval the framework components were drawn to create a set of manufacturing drawings. The fabricated Package was then delivered to site and erected by our client.

Structural steelwork
